Lumin AMP er den perfekte partner til din Lumin Streamer, men den er også glimrende sammen med hva som helst annet av forforsterkere eller andre streamere. En særdeles vellydende forsterker som kan brukes som stereoforsterker, en dual mono forsterker eller som brokoblet kraftverk.
DEDICATED AMPLIFICATION
Looking for the perfect partner for your LUMIN Music Streamer? Look no further. Engineered to let your LUMIN sing!
WHY LUMIN AMP
Featuring everything you need and nothing you don't, LUMIN Amp focuses purely on performance. If your LUMIN streamer sounded like a breath of fresh air, prepare to take it to the next level.
Matched styling.
Unmatched performance.
Multi-Stage transistors amplifier
Dual Mono power supply and amplifier design
Fully discrete voltage and current gain stages
DC-coupled signal path
Class AB operation
High input impedence and sensitivty for direct DAC drive
Intelligent bias and thermal management
Stereo / Dual Mono / Bridged operation
CNC single billet aluminium construction
600VA custom toroidal transformer
Built-in overload, overheat and DC protection
SPECIFICATION
LUMIN AMP SPECIFICATION
OPERATING MODE: (selectable)
Stereo, Dual Mono or Bridged mode
INPUT: (selectable)
1 x XLR pair (pin 2 hot), 1 x RCA pair
POWER:
160W per channel into 8?
320W per channel into 4?
640W into 8? (Bridged)
POWER SUPPLY:
Available in 220?240V AC and 110?120V AC versions ~ 50/60Hz
POWER CONSUMPTION:
Standby <0.5W
Idle 40W
Max 700W
FREQUENCY RESPONSE:
20hz - 40000hz ± 0.1db
SIGNAL TO NOISE RATIO:
103db, unweighted
INPUT IMPEDANCE:
200k? Balanced (XLR)
100k? Unbalanced (RCA)
OUTPUT IMPEDANCE:
0.1?
INPUT SENSITIVITY:
1.16Vrms
GAIN:
+26dB (Stereo, Dual Mono)
+32dB (Bridged)
PROTECTION:
DC, overload and overheating protection
FINISHES:
Black anodized brushed aluminium or Raw brushed aluminium
CONSTRUCTION:
CNC-machined from a single billet for front, top and sides. Thick 8mm walls, rear panel and base plate
DIMENSIONS:
350mm (W), 374mm (D), 104mm (H)
WEIGHT:
19kg
DEDICATED AMPLIFICATION
Looking for the perfect partner for your LUMIN Music Streamer? Look no further. Engineered to let your LUMIN sing!
WHY LUMIN AMP
Featuring everything you need and nothing you don't, LUMIN Amp focuses purely on performance. If your LUMIN streamer sounded like a breath of fresh air, prepare to take it to the next level.
Matched styling.
Unmatched performance.
Multi-Stage transistors amplifier
Dual Mono power supply and amplifier design
Fully discrete voltage and current gain stages
DC-coupled signal path
Class AB operation
High input impedence and sensitivty for direct DAC drive
Intelligent bias and thermal management
Stereo / Dual Mono / Bridged operation
CNC single billet aluminium construction
600VA custom toroidal transformer
Built-in overload, overheat and DC protection
SPECIFICATION
LUMIN AMP SPECIFICATION
OPERATING MODE: (selectable)
Stereo, Dual Mono or Bridged mode
INPUT: (selectable)
1 x XLR pair (pin 2 hot), 1 x RCA pair
POWER:
160W per channel into 8?
320W per channel into 4?
640W into 8? (Bridged)
POWER SUPPLY:
Available in 220?240V AC and 110?120V AC versions ~ 50/60Hz
POWER CONSUMPTION:
Standby <0.5W
Idle 40W
Max 700W
FREQUENCY RESPONSE:
20hz - 40000hz ± 0.1db
SIGNAL TO NOISE RATIO:
103db, unweighted
INPUT IMPEDANCE:
200k? Balanced (XLR)
100k? Unbalanced (RCA)
OUTPUT IMPEDANCE:
0.1?
INPUT SENSITIVITY:
1.16Vrms
GAIN:
+26dB (Stereo, Dual Mono)
+32dB (Bridged)
PROTECTION:
DC, overload and overheating protection
FINISHES:
Black anodized brushed aluminium or Raw brushed aluminium
CONSTRUCTION:
CNC-machined from a single billet for front, top and sides. Thick 8mm walls, rear panel and base plate
DIMENSIONS:
350mm (W), 374mm (D), 104mm (H)
WEIGHT:
19kg
- Originalemballasje
- Ja
- Orig. kvittering
- Ja
- Forsendelse
- Kan sendes
