Canor DAC 2.10
D/A converter with tube-based output
CANOR DAC 2.10 uses the dual mono configuration of the ES9038Q2M digital-to-analogue converters from ESS Sabre, which ensure high sound quality.

Dette er en særdeles god DAC, som virkelig har overrasket! Har du en cd spiller eller en streamer så vil denne garantert gi deg en oppgradering.


Product features

  • thanks to used converters, it is possible to play files in PCM formats up to a sampling frequency of 768 kHz and for DSD format up to Native DSD512 via the USB input, thus covering most digital files that you can normally play, buy or stream.
  • it uses the dual mono configuration of the ES9038Q2M digital-to-analogue converters from ESS Sabre, which ensure high sound quality.
  • the analogue output is a buffer, which is solved by a high-quality electronic connection
  • dual converter wiring uses separate signal paths for the left and right channels.
  • there are seven digital converter filters for PCM format and one proprietary for MQA format, which is set automatically during MQA playback.
  • the last (eighth) item in the digital filter menu “Oversampling Bypass” can be selected. But it’s not a digital filter, as it’s turning off digital filtering for the ability to compare audio without filtering…
  • the signal from the digital inputs is processed by a powerful multi-core XMOS microcontroller with an advanced Multi-Core RISC architecture.

Frequency Response at Fs=192 kHz+/- 0,03 dB at 20 Hz to 20 kHz
Output impedance< 200 Ω
THD+N 1kHz at 0 dBFs> 0,008%
THD+N 1kHz at -6 dBFs> 0,004%
XLR output voltage at 0 dBFs4 V RMS
XLR: SNR 20 Hz to 20 kHz at 0 dBFs< 108 dB
RCA output voltage at 0 dBFs2 V RMS
RCA: SNR 20 Hz to 20 kHz at 0 dBFs< 95 dB
Analogue outputs2 x XLR / 2 x RCA
Supported PCM sampling rates44,1k / 48k / 88,2k / 96k / 176,4k / 192k / 352,8k / 384k / 705,6k / 768kHz
DSD over PCM supportDoP DSD 64/128/256/512
DSD Native supportNative DSD 64/128/256/512
MQA supportFull MQA decoding by hardware from all digital inputs
S/PDIF Optical input2 x (24bit / 192kHz)
S/PDIF Coaxial input1 x (24bit / 192kHz)
AES/EBU input1 x (24bit / 192kHz balanced)
Digital to Analogue converter2 x ESS9038Q2M (dual mono)
Filter settings8 x digital filter
DisplayLCD TFT
Tube complement4 x 6922
Power230 V / 50 Hz / 44 VA
Dimensions (w x h x d)435 x 120 x 405 mm
Weight (net)12 kg
