Vurderer å selge min McIntosh MA7000. Ev. bytte i Devialet.
Teknisk og utseendemessig strøken. Det er byttet utgangstransistorer og drivere for 1 år siden hos Neby i Oslo. Dette kostet 8.600,-
Veiledende nypris: 65.000,- https://www.prisjakt.no/product.php?pu=396497
Selges gunstig til 35.000,-
Har originalemballasje, fjernkontroll og alt av papirer. Må hentes pga. høy vekt, 60 kg. inkl. emballasje. Kan ev. kjøre i møte om ikke avstanden er for lang.
Kan besiktiges og testes på Nesttun.
Brosjyre: http://www.berners.ch/McIntosh/Downloads/MA7000_bro.pdf
Brukermanual: http://www.berners.ch/McIntosh/Downloads/MA7000_own.pdf
Test: http://www.lydogbilde.no/test/mcintosh-ma7000
Spesifikasjoner:
Power Output: 250 watts is the minimum sine wave continuous average power output per channel, both channels operating
Output Load Impedance: 2, 4 or 8 ohms
Rated Power Band: 20Hz to 20,000Hz
Total Harmonic Distortion: 0.005% maximum with both channels operating from 250 milliwatts to rated power, 20Hz to 20,000Hz
Dynamic Headroom: 2.0dB
Frequency Response:
+0, -0.5dB from 20Hz to 20,000Hz
+0, -3dB from 10Hz to 100,000Hz
Preamplifier Main Output (for rated input)
2.5V unbalanced (8V Maximun)
5.0V balanced (16V Maximun)
Sensitivity (for rated output):
High Level, 250mV unbalanced, 500mV balanced
Phono, 1.2 mV
Power Amp In, 2.5V
Signal To Noise Ratio (A-Weighted)
High Level, 100dB below rated output
Phono, 84dB below 5mV input
Power Amplifier, 115 below rated output
Intermodulation Distortion: 0.005% maximum, if the instantaneous peak power is 500 watts or less per channel with both channels operating for any combination of frequencies from 20Hz to 20,000Hz
Wide Band Damping Factor: Greater than 40
Input Impedance:
High Level, 20K ohms
Phono, 47K ohms; 65pF
Power Amp In, 10K ohms
Maximum Input Signal:
High Level, 8V unbalanced, 16V balanced
Phono, 45mV
Power Amplifier In, 16V
Main Output Impedance: 50 ohms
Power Guard: Less than 2% THD with up to 16dB overdrive at 1,000Hz
Voltage Gain:
High Level to Rec Output: 0dB
High Level to Main Output: 20dB
Phono to Rec Output: 46dB
Phono to Main Output: 66dB
Power Amplifier: 25dB
Equalizer Controls: Variable 12dB boost to 12dB cut at 30Hz, 150Hz, 500Hz, 1500Hz and 10,000Hz
Power Requirements
100 Volts, 50/60Hz at 8.0 amps
110 Volts, 50/60Hz at 7.2 amps
120 Volts, 50/60Hz at 6.6 amps
220 Volts, 50/60Hz at 3.3 amps
230 Volts, 50/60Hz at 3.3 amps
240 Volts, 50/60Hz at 3.3 amps
Standby: Less than 1 watt
Note: Refer to the rear panel of the MA7000 for the correct voltage.
Overall Dimensions
Width is 17-1/2 inches (44.45cm)
Height is 9-7/16 inches (23.97cm) including feet
Depth is 22 inches (55.88cm) including the Front Panel, Knobs and Cables
Weight: 97.5 pounds (44.3 kg) net, 130.5 pounds (59.2 kg) in shipping carton
Shipping Carton Dimensions
Width is 29-1/2 inches (74.93cm)
Depth is 29 inches (73.66cm)
Height is 17 inches (43.18cm)
